EX-H510M-V3-SI
Sản phẩm
Bo mạch chủ
Tên Hãng
Asus
Model
EX-H510M-V3
CPU hỗ trợ
Intel
Chipset
H510
RAM hỗ trợ
2 x DIMM, Max. 64GB, DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC
Khe cắm mở rộng
Intel® 11th & 10th Gen Processors
1 x PCIe 4.0/3.0 x16 slot
- Intel® 11th Gen processors support PCIe 4.0 x16 mode
- Intel® 10th Gen processors support PCIe 3.0 x16 mode
Intel® H510 Chipset
1 x PCIe 3.0 x1 slot
Ổ cứng hỗ trợ
Total supports 3 x SATA 6Gb/s ports
Intel® H510 Chipset
3 x SATA 6Gb/s ports
Cổng kết nối (Internal)
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 4-pin +12V Power connector
Storage related
3 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports
Miscellaneous
1 x Clear CMOS header
1 x Front Panel Audio header (AAFP)
1 x Speaker header
1 x 10-1 pin System Panel header
Cổng kết nối (Back Panel)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
1 x HDMI™ port
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard (purple) port
1 x PS/2 Mouse (green) port
LAN / Wireless
1 x Realtek 1Gb Ethernet
Kích cỡ
microATX
18.8cm*21.3cm
